W1147 – Schott Zerodur Exp. Class 2, 127mm x 90mm ellipse x 10mm thk.

Name: W1147 - Schott Zerodur Exp. Class 2, 127mm x 90mm ellipse x 10mm thk.
Brand: Sydor Optics
SKU: W1147
Price: 200 USD
Availability: InStock

$200.00

Product Attributes

Material/Grade: Schott Zerodur, Exp. Class 2

Thickness: 10.00mm ±0.10mm

Length: 127.00mm ±0.50mm (major axis)

Width: 90.00mm ±0.50mm (minor axis)

Metrology Wavelength: 633nm

Clear Aperture (CA): elliptical, 113mm x 80mm +10mm/-0mm

Reflective Wavefront: S1: <30nm RMS (w/ up to 0.5 wvs Pwr removed)

Parallelism: 0.010mm

Bevel(s): 0.7mm ±0.5mm LEG @ 45° ±10°

Chips: <0.25mm

Cosmetics: S1: 60/40, S2: 80/50

Edge Finish: Fine Edge Ground

Roughness: <0.002um (20Å) RMS

47 in stock

Quality Levels

Choose an option

As is. C of C only

Full inspection with interferograms (+$50.00)

Full inspection with interferograms

Product price:	$200.00
Total options:
Order total:

Looking for volume pricing?

Request a Quote

SKU: W1147 Categories: Tier 4 (QC Level 2), Uncategorized, Zerodur

Additional information

Additional information

Weight	8 oz
Dimensions	649131626 × 6495772 mm
